VK-RZ/V2L

Single Board Computer
	Equipped with: ---------------- R9A07G054L23GBG (Dual 1.2GHz ARM Cortex-A55 + Single 200MHz Cortex-M33) 1-2GB DDR4 RAM 8-128GB eMMC 16-32MB QSPI Flash 2x Gigabit ETH (1 of which is PoE) uHDMI Video out MIPI-DSI Video FPC MIPI-CSI Camera FPC 3.5mm Audio uSD Card Holder 2x USB Type A 2x CAN FD User BTN 4x UserLEDs 6 ADC Input USB Type C Power ---------------- Flyer Brochure: [Renesas] \| latest Block Diagram: latest 3D Board View (step) 40Pin HAT Board: latest Interface FW: latest U-boot: Source Yocto v3.1.xx (Dunfell) images for VK-RZ/V2L: ┣━ [ Yocto bsp IMG for VK-RZ/V2L \| Bmap ] (18.03.24) ┣━ [ Yocto weston (openCVA) IMG for VK-RZ/V2L \| Bmap ] (21.02.25) ┣━ [ Yocto Qt IMG for VK-RZ/V2L \| Bmap ] (--.--.--) ┣━ [ Yocto SDK (openCVA) for VK-RZ/V2L ] (05.12.24) ┗━ Yocto Build Recipe for VK-RZ/V2L \| Install Debian v12.x (Bookworm) images for VK-RZ/V2L: ┣━ [ Debian LXDE IMG for VK-RZ/V2L \| Bmap ] (21.02.25) ┣━ [ Debian console IMG for VK-RZ/V2L \| Bmap ] (19.01.24) ┗━ Debian Build Recipe for VK-RZ/V2L \| Install Home Assistant (Debian v12.x) image for VK-RZ/V2L: ┗━ [ HA IMG for VK-RZ/V2L \| User: test \| Pass: ~VjZ^i=!Zt8Vym9 ] (19.01.24)) Libs for VK-RZ/V2L: ┗━ OpenCV v4.1.0 (Debian) [ Src \| Bin ] Examples for VK-RZ/V2L: ┣━ OpenCV Accelerator (Cpp) [ Src \| Yocto Bin \| Debian Bin \| Png ] ┗━ OpenCV Accelerator (Py) Py How to: ┣━ Get Start with VK-RZ/V2L ┣━ run RDP in Yocto with VK-RZ/V2L ┣━ run OpenCV in Debian with VK-RZ/V2L ┗━ Compile U-boot for VK-RZ/V2L Settings
